GR 1000
GR 1000
GR 1000

GR 1000

Sale price$0.00
Sold out

Tax excluded.

Wattage: 1000W

Overview

Video

True Free-Floating Structural Separation

Conventional design squeezes both the PSU - a prime source of heat - and critical components in the same space, restricting airflow access to only the top, front and rear panels. The Central Floating Ventilation divides the PSU cabin and main chamber with a structural hollow that lets air move with greater freedom and purpose. This free-floating architectural separation also gives the CFV235 series its unique, progressive visual identity.

270° Airflow Access Within Suspended Space

The CFV235 series’ floating space is a fully 3 dimensional, discrete void suspended within the chassis. 270° of spacious, unobstructed airflow intake delivers greater ventilation than enclosed layouts to where it’s most needed.

Pre Installed Reverse Blade Unity ARGB 240 Fans

Unity ARGB 240 Fans


COUGAR Unity ARGB 240 single-frame PWM reverse-blade fans are preinstalled on the motherboard side, providing precise fan speed control, exceptional cooling, near-silent operation, and stunning RGB lighting straight out of the box.

The Aurora lighting strip lights up with the integrated space of the Central Floating Ventilation structure from within, highlighting this innovative feature and displaying it as an architectural reinvention. It’s included with the case and attaches magnetically for ease and convenience.

The Rainbow In Between

CFV235 / Mesh / Vision series

Choose which one you need.

Sold out
CFV235CFV235
CFV235 Sale price$4,200.00
Color

Light. Speed

The CFV235 features an integrated universal fan hub that enables seamless coordination of PWM fan speed and RGB lighting. This allows you to control the RGB lighting without the need for software, or synchronize it with motherboard software.

Dual Magnetic Filtration

Magnetic dust filters at the roof and base of the Central Floating Ventilation structure proactively prevent dust and debris buildup, keeping airflow clean and uninterrupted without disrupting the suspended design.

Just grab the protruding tag and pull: it’s that easy to clean the filter.

Dust filters attach magnetically to protect the separated PSU cabin and main chamber from dust and other particles.

Vertical Spatial Efficiency

The placement of the central floating ventilation channel on a vertical axis avoids expanding the overall width, keeping the footprint tight.

Before

After

Drag

Architectural Strength

A 1.5mm-thick steel frame reinforces the chassis, preserving structural integrity even with the suspended central ventilation design. The result is a bold, open architecture that stays rigid, reliable, and ready for high-performance builds.

Space Engineering

38mm of clearance behind the motherboard tray improves cable management ,offering more room to route and conceal cables of varying thickness. Five adjustable Velcro straps offer versatile options to secure and tidy your layout.

Space Engineering

38mm of clearance behind the motherboard tray improves cable management ,offering more room to route and conceal cables of varying thickness. Five adjustable Velcro straps offer versatile options to secure and tidy your layout.

Versatile Compatibility

Compatible with reverse connector motherboards and accommodating GPUs of up to 430mm, the CFV235 is engineered for the gaming rigs of the future. An L–shaped GPU mounting bracket with flexible installation options protects against GPU sag.

Peripheral Vision

The CFV235 is equipped with USB 3.2 Gen 2x2 Type-C (20 Gbps) x1, USB 3.0 Type-A x 2, 4 pole headset audio jack for versatile device and peripheral connectivity

Cooling Capacity

The CFV235 has a fan capacity of 3x120mm or 3x140mm on the top, 3x120mm on the floor of the main chamber, 2x120mm fans on the motherboard side, and 1x120mm (pre-installed) on the rear. Water cooling support maxes out at 360mm on the top.

Water Cooling Radiator Support

Cooling Fan Support

Full House

Accommodating 2x3.5” HDD drives and 2+2 2.5” SSD drives (converted from 3.5” drive bays), versatile storage options gives you plenty of room to expand your storage as needed.

3.5” HDD

2.5” SSD

Comparison

CFV235
CFV235 Sale price$4,200.00
Black White
Product
Product
CFV235
CFV235 Sale price$4,200.00
Black White
Product
Product
Front Panel

Glass

Glass

3-in-1 Module

PWM and RGB hub Sync with M/B

Yes

Yes

Yes

Aurora LED Strip

Yes

Yes

Yes

9.16" LCD Monitor (1920 x 462 px)

No

Yes

No

Pre-installed Fans

Front: No
M/B Side: Unity 240 ARGBPWM Reversed fan x 1
Bottom: No
Rear: 120mm ARGB PWM fan x 1

Front: No
M/B Side: Unity 240 ARGBPWM Reversed fan x 1
Bottom: No
Rear: 120mm ARGB PWM fan x 1

Front: 160mm ARGB PWM fan x 2
M/B Side: No
Bottom: No
Rear: 120mm ARGB PWM fan x 1

Cooling Fan Support

Front: No
Top: 120mm x 3 / 140mm x 3
M/B Side: 120mm x 2
Bottom: 120mm x 3
Rear: 120mm x 1

Front: No
Top: 120mm x 3 / 140mm x 3
M/B Side: 120mm x 2
Bottom: 120mm x 3
Rear: 120mm x 1

Front: 160mm x 2
Top: 120mm x 3 / 140mm x 2
M/B Side: No
Bottom: 120mm x 3
Rear: 120mm x 1

Max. Graphics Card Length

430mm / 16.9in

430mm / 16.9in

400mm / 15.7in

Specifications

Motherboard Type

Mini ITX / Micro ATX / ATX / CEB

Dimensions (WxHxD)

235 x 493 x 460 (mm)
9.3 x 19.4 x 18.1 (in)

I/O Panel

USB 3.2 Gen 2x2 Type-C x 1, USB 3.0 Type-A x 2, 4 Pole Headset Audio Jack x 1, RGB Button

3.5" Drive Bay

2

2.5" Drive Bay

2+2 (converted from 3.5" drive bays)

Expansion Slots

7

Cooling Fan Support

Top: 120mm x 3 / 140mm x 3
M/B Side: 120mm x 2
Bottom: 120mm x 3
Rear: 120mm x 1

Pre-installed Fans

M/B Side: Unity 240 ARGB PWM Reversed fan x 1
Rear: 120mm ARGB PWM fan x 1
Speed: Unity 240 ARGB PWM Reversed fan: 700-1600 RPM ±10%
120mm ARGB PWM fan: 500-1400 RPM ± 10%
Connector: 5V 3 Pin (ARGB) / 4 Pin PWM (Fan)

Maximun Number of Fans

9

Packing Data

Individual Size W/O Packaging
Weight (N.Weight): 9.5 (kg)

Individual Packaging
Weight (G.Weight): 11.8 (kg)

Individual Size W/O
Packaging (LxWxH): 235 x 493 x 460 (mm)

Individual Packaging
Size (LxWxH): 542 x 578 x 317 (mm)
